Dwyer 數字校準壓力表 DCGII系列

±0.05% FS Accuracy, 316 SS Wetted Parts

DCGII系列數字校準壓力表提供具有校準功能的完整壓力表。具有精確的0.05%全量程精度和大5位分辨率，該儀表可用于關鍵的工業應用，精度是最重要的。這種多功能壓力表只需要一個9V電池或電源適配器，可以操作多達5000個工作小時。該系列DCGII 0.05%數字壓力計可以顯示百分比量程，壓力波動或報警設定點。這種壓力表配有11個可選擇的壓力單元，背光和歸零功能。

校準選項可在附件。

應用及案例

? Field gage calibration

? Permanent installation

? Burst disc testing

? Torque data logging

? Pressure regulator testing and hydrostatic leak testing

產品特色技術指標選項配件安裝手冊機構認證尺寸詳圖產品大圖型號列表訂貨選型宣傳彩頁

產品特色

? Indicator can display percent of range, pressure swings or alarm set points

? Minimum and maximum peak detection

? Selectable 10, 20, or 30 second backlight

? Temperature indication

? Eleven selectable pressure units

? Stainless steel 1/2" male NPT connection

? Highest accuracy provides exceptional measurement for calibration minimizing costly out of specification conditions

? Stainless steel housing resists ambient corrosion for longer service life in harsh environments

? Lightweight and slim, yet large easy to read battery-powered gage make them easy to carry and read

? Specified with high ambient temperature rating means more robust uses and longer service-life

? Indicator can display pressure swings, minimum and maximum peak detection with alarm set points provides a multipurpose tool where critical calibration is needed
